Wedge Wire Screen is a type of filter media constructed from specially shaped wires. The profile wires are precisely aligned and welded to support rods using advanced automatic resistance welding technology. Both the profile and support wires can be made in various cross-sectional shapes, including wedge, water drop, circular, or keystone designs. Wedge wire screens are typically available in two main forms: slotted tubes (cylindrical filter elements) and flat screens (sieves).
▎Product Advantage
Precise Openings – Ensures accurate and consistent filtration performance for various applications.
Fast Drainage & High Filtration Efficiency – Provides excellent flow capacity, allowing liquid to drain quickly while maintaining filtration accuracy.
Smooth & Flat Surface – Prevents clogging and ensures stable, uniform filtration.
Flexible Design Options – Can be customized in size, shape, and structure to meet specific industrial requirements.
High Strength & Durability – Built to withstand heavy loads and pressure drops, offering long-term, economical performance.
Easy Installation & Long Service Life – Simple to assemble and maintain, ensuring reliable operation over time.
High Mechanical Strength – Capable of bearing large pressure drops without deformation or loss of efficiency.
▎Technical Parameters
| Wedge Wire Screen | |||||||
Material | Galvanlzed Low Carton (LCG) Stainless Steel (304 316 etc) | ||||||
Wedge Wire | Width (mm): 1.5, 1.8, 2.3, 3.0, 3.3, 3.7, 4.0, 4.5 | ||||||
Support Rod | Width (mm): 1.5, 1.8, 2.3, 3.0, 3.3, 3.7, 4.0, 4.5 | ||||||
Slot Size | 0.05, 0.08, 0.1, 0.15, 02, 0.25, 0.3… 6.0mm Also Achieved Upon Request | ||||||
Length | Up To 6 Meters | ||||||
Diameter | 25-1200mm | ||||||
End Connection | Plain Beveled Ends For Welding Or Threaded Male &Female Coupling(Spiral) | ||||||
| Other Specifications Available Upon Request | |||||||
| Technical Parameter | |||||||
Size (inch) | OD (mm) | Slot (inch) | Length (m) | Collapse | Tensile | Wire Size (mm) | RODS (mm) |
4 | 117 | 0.04 | 3 | 395 | 6 | 2.2*3.0 | 3.8mm/22 |
4 | 114.3 | 0.04 | 3 | 395 | 6 | 2.3*3.0 | 3.8mm/22 |
6 | 168.3 | 0.04 | 3 | 252 | 8 | 2.3*3.5 | 3.8mm/32 |
8 | 219.1 | 0.01 | 3 | 399 | 10.5 | 3.0*5.0 | 3.8mm/48 |
8 | 219.1 | 0.02 | 3 | 370 | 10.5 | 3.0*5.0 | 3.8mm/48 |
8 | 219.1 | 0.04 | 3 | 323 | 10.5 | 3.0*5.0 | 3.8mm/48 |
0 | 273.1 | 0.01 | 3 | 206 | 11 | 3.0*5.0 | 3.8mm/50 |
0 | 273.1 | 0.02 | 3 | 191 | 11 | 3.0*5.0 | 3.8mm/50 |
0 | 273.1 | 0.04 | 3 | 167 | 11 | 3.0*5.0 | 3.8mm/50 |
▎Product Uses
Wedge wire screens are widely used across various industries, including mining, coal, petroleum, fertilizer, grain, salt production, and environmental protection. They are ideal for sieving liquids, powders, and other materials.
In addition, they are extensively applied in petroleum and chemical processing, metallurgical and mining operations, pharmaceutical purification, and drilling fluid filtration, providing reliable and efficient solid–liquid separation in demanding industrial environments.
▎Product Video
▎FAQ
Q: How can I pay for my order?
A: We accept T/T (bank transfer), Western Union, and Alibaba Online Payment for your convenience.
Q: Are you a manufacturer or a trading company?
A: We are a professional manufacturer with standard workshops and advanced precision machining equipment. Customers are welcome to visit our factory in person or schedule a video tour.
Q: What is the minimum order quantity (MOQ)?
A: Our MOQ is 1 piece. As a direct factory, we can also customize single-piece orders to meet your specific requirements.
Q: Can I customize the product?
A: Absolutely. Our experienced technical team can customize and produce various filter elements based on your drawings or specific needs. We can also assist in designing drawings according to your requirements.
